Description:

Each GCC vinyl cutter delivers precise tracking capabilities, superior cutting speeds, unrivaled cutting forces, reliable performance, and innovative features. GCC vinyl cutters are a perfect solution for entry-level to professional users and also an ideal stage for a broad range of applications across a number of industries, covering the sign, advertisement, textile, vehicle fields, and so forth. GCC vinyl cutters are the best business partner along your path to success.



SPECIFICATION;

Model Number : Ar-24

Operational Method : Roller Type

Max. Cutting Width : 600 Mm (23.6”)

Max. Media Loading Width : 719 Mm (28.03”)

Number Of Pinch Rollers : 3

Acceptable Materials Thickness : 0.8 Mm (0.03”)

Drive Motor: Stepper Motor

Cutting force : 5-250 g

Max. cutting speed (diagonal) : 552 mm/sec (21.7 IPS) (at 45^o direction)

Offset : 0-1.0 mm (with 0.025 mm increment)

Memory buffer : 32 MB

Interfaces : USB 2.0 (Full Speed), Serial (RS-232c)

Type Of Command : HP-GL, HP-GL/2

Mechanical Resolution : 0.012 mm

Software Resolutuion : 0.025 mm

Distance Accuracy : +0.254 mm or + 0.1%  Move, Whichever Is Greater

Repeatability : +0.1 mm (Certified Media)

Over Cut : N/A

Curve & Arc Smoothing : Yes

Configurable Origin : Yes

Tangential Mode : N/A

Repeat : Yes

Copy : N/A

Diameter Of Blade : 2.5 Mm

Control Key : 10 Keys / 2 LEDs

Power Supply : AC Adapter, 24V DC (1.67A)

Power Consumption : 40 Watts

Stand : Optional

Operation Temperature: 15^oC -30^oC/ 60^oF -86^oF

Operation Humidity: 25%-75%
