DESCRIPTION:
CNC routers can cut a variety of materials, including wood, plastic, aluminium, and high-density foam. CNC stands for computer numerical control, and it refers to machines that are operated by computer software and electronics rather than by a human operator.
CNC machines can cut in three directions, known as the X, Y, and Z axes, in most circumstances. The longest axis is the X-axis, which runs from front to back. The Y-axis represents left and right, whereas the Z-axis represents up and down. CNC routers are faster and more exact than people since they run on computers, making them valuable in manufacturing.
Features:
- 4 heads, the head can work at the same time
- Constant Power water cooling spindle, Higher working strength.
- Japanese FUJI SERVO motor, higher working precision
- Diameter, length of rotary can manufacture according to client’s need.
SPECIFICATIONS:
| X-Y Axis Working Area | 1300 x 2500 mm |
| Z Axis Working Area | 190 mm |
| Spindle Power | 3.5 kW |
| Model | EC-1325 |
| Control System | Digital Signal Processor (DSP) |
| Brand | Max-Tech |
| Operating System | Rich Auto A11B |
| Spindle | Air Cooled |
| X-Y Movement | Rack & Pinion |
| Z movement | Ball Screw |
| Spindle Speed | 6000-18000 rpm |
| Variable Frequency Drive | Best |
| Drive | CW Stepper Motor (Yakoo Make) |
| Job Material | MDF, Wood, Sign Board, HDF, PVC, Acrylic, Foam Board, Plywood |
| Power Supply | AC 230V/50hz/Single Phase |
| Weight | 1100 kg |
